TwinCAT 3 由 TwinCAT 3 开发环境(TwinCAT 3 Engineering,XAE)和 TwinCAT 3 运行时环境(TwinCAT 3 Runtime,XAR)构成。
TwinCAT 3 开发环境(PLC 编程)是免费的,并可安装在任意数量的开发 PC 上。但超出纯 PLC 编程的额外功能/开发工具(TExxxx)以及 TwinCAT 3 运行时 授权(TCxxxx/TFxxxx)需要收费。
TwinCAT 3 运行时的授权价格取决于所使用的工业 PC 的性能。性能被细分为各种平台等级。
TwinCAT 3 授权可以直接在工业 PC 上激活, 但我们建议使用 TwinCAT 3 授权加密狗。
对于当前的 TwinCAT 3 版本(Build 4022 以上),TwinCAT 3 授权可以方便地通过授权密钥 U 盘 C9900-L100/-L101/-L102 或者 EtherCAT 授权密钥端子模块 EL6070、EL6071 或 EL6072 订购,然后可以立即投入使用。
用户可以随时给 TwinCAT 3 授权加密狗添加额外的授权文件。一个 TwinCAT 3 授权加密狗最多可以有 20 个授权文件,每个文件的授权数量不限。
TwinCAT 3 授权加密狗可以让 TwinCAT 3 授权独立于正在使用的工业 PC。通过该加密狗,可以简单地更换工业 PC 或在不同的工业 PC 上使用授权。
TwinCAT 3 授权加密狗支持平台等级向下兼容。一个较高平台等级的授权可用于所有较低的平台等级。
TwinCAT 授权加密狗 (第一代)
EL6070 | EtherCAT Terminal, license key for TwinCAT 3.1
TwinCAT 3.1 offers an option to manage TwinCAT software licenses via the EtherCAT Terminal EL6070. The EL6070 embodies the hardware license key in the modular EtherCAT I/O system. Data transfer takes place via EtherCAT.
C9900-L100 | License key USB stick for TwinCAT 3.1
As an alternative to the EL6070 license key terminal, the TwinCAT licenses can also be managed using the C9900-L100 USB stick. Data transfer takes place via USB.
EJ6070 | EtherCAT plug-in module, license key for TwinCAT 3.1
TwinCAT 3.1 offers an option to manage TwinCAT software licenses via the EtherCAT plug-in module EJ6070. The EJ6070 embodies the hardware license key in the modular EtherCAT I/O system. Data transfer takes place via EtherCAT.
EP6070-0060 | EtherCAT Box, license key for TwinCAT 3.1
TwinCAT 3.1 offers an option to manage TwinCAT software licenses directly in distributed systems via the IP67-protected EP6070-0060 EtherCAT Box module. The EP6070-0060 embodies the hardware license key in the modular EtherCAT I/O system. Data transfer takes place via EtherCAT.
TwinCAT 授权加密狗 (第二代)
EL6071 | EtherCAT Terminal, license key for TwinCAT 3.1
TwinCAT 3.1 offers the option of managing TwinCAT licenses via license key devices. The EL6071 embodies the hardware license key in the modular EtherCAT I/O system. It is equipped with a local data memory for storing TwinCAT 3.1 license files. Communication takes place via EtherCAT.
EL6072 | EtherCAT Terminal, license key for TwinCAT 3.1, with RTC
TwinCAT 3.1 offers the option of managing TwinCAT licenses via license key devices. The EL6072 embodies the hardware license key in the modular EtherCAT I/O system. It is equipped with a local data memory for storing TwinCAT 3.1 license files. Communication takes place via EtherCAT.
C9900-L101 | License key USB stick for TwinCAT 3.1
TwinCAT licenses can be managed via license key devices in TwinCAT 3.1.
C9900-L102 | License key USB stick for TwinCAT 3.1, with RTC
TwinCAT licenses can be managed via license key devices in TwinCAT 3.1.
