TF6105 | TwinCAT 3 OPC UA Pub/Sub

TF6105 | TwinCAT 3 OPC UA Pub/Sub

TF6105 | TwinCAT 3 OPC UA Pub/Sub

TF6105 | TwinCAT 3 OPC UA Pub/Sub

TF6105 | TwinCAT 3 OPC UA Pub/Sub

TwinCAT 3 OPC UA Pub/Sub extends the OPC UA client/server architecture to include publisher/subscriber communication patterns. The TF6105 TwinCAT 3 OPC UA Pub/Sub provides the necessary implementations of the protocol so that these kinds of communication patterns can be readily integrated into the TwinCAT application. It includes various transport protocols as defined in the corresponding OPC UA specification part (OPC10000-14), e.g. UDP and MQTT.

Product status:

product announcement | est. market release 2nd quarter 2024 exclusively with TwinCAT 3.1 Build 4026

Product information

Technical dataTF6105
Required licenseTC1100
Operating systemWindows 7, Windows 10, TwinCAT/BSD
CPU architecturex86, x64
Ordering information
TF6105-0v40TwinCAT 3 OPC UA Pub/Sub, platform level 40 (Performance)
TF6105-0v50TwinCAT 3 OPC UA Pub/Sub, platform level 50 (Performance Plus)
TF6105-0v60TwinCAT 3 OPC UA Pub/Sub, platform level 60 (Mid Performance)
TF6105-0v70TwinCAT 3 OPC UA Pub/Sub, platform level 70 (High Performance)
TF6105-0v80TwinCAT 3 OPC UA Pub/Sub, platform level 80 (Very High Performance)
TF6105-0v81TwinCAT 3 OPC UA Pub/Sub, platform level 81 (Very High Performance)
TF6105-0v82TwinCAT 3 OPC UA Pub/Sub, platform level 82 (Very High Performance)
TF6105-0v83TwinCAT 3 OPC UA Pub/Sub, platform level 83 (Very High Performance)
TF6105-0v84TwinCAT 3 OPC UA Pub/Sub, platform level 84 (Very High Performance)
TF6105-0v90TwinCAT 3 OPC UA Pub/Sub, platform level 90 (Other)
TF6105-0v91TwinCAT 3 OPC UA Pub/Sub, platform level 91 (Other 5…8 Cores)
TF6105-0v92TwinCAT 3 OPC UA Pub/Sub, platform level 92 (Other 9…16 Cores)
TF6105-0v93TwinCAT 3 OPC UA Pub/Sub, platform level 93 (Other 17…32 Cores)
TF6105-0v94TwinCAT 3 OPC UA Pub/Sub, platform level 94 (Other 33…64 Cores)

We recommend using a TwinCAT 3 license dongle for platform levels 90-94.
